Antiwear Patterned Aluminium Perforated Plate Sheet Metal 4047 Practical

Wuxi Ninghang Stainless Steel Export & Import Co.,Ltd.
Contact Now

Antiwear Patterned Aluminium Perforated Plate Sheet Metal 4047 Practical

  • 1
  • 2
  • 3

Model Number : 4047

Certification : Material Test Certificate

MOQ : 1 PC

Price : Translation Price

Payment Terms : L/C At Sight T/T Western Union

Supply Ability : 3000Tons/Month

Delivery Time : 10-15 work days

Packaging Details : Kraft Paper Wooden Pallet Wooden Box

Product Name : 4047 Aluminium Perforated Metal Sheet

Material : 4047

Usage : Filters, decoration

Shape : Various Pattern

Alloy Or No : Alloy

Hole shape : Customized

Contact Now

Various Pattern Customized 4047 Aluminium Perforated Metal Sheet

Product Description

Chemical Composition

Elements Si Fe Cu Mn Mg Zn Ti Others Al
Contents 11.0-13.0 0.8 0.3 0.15 0.1 0.2 0.15 0.05 balance

Mechanical Properties

Temper Thickness Tensile Strength Yield Strength Elongation
4047-H18 0.05-0.1 mm ≥200 MPa ≥170 MPa Min. 0.5 %

Product Display

4047 aluminum is one of 4000 series alloys. 4 series aluminum alloys are aluminum alloys with silicon as the main alloying element. Most of the alloys are heat-treated non-strengthable aluminum alloys, which refer to alloys containing Cu, Mg, and Ni, as well as welding heat treatment strengthening After the alloy has absorbed certain elements, it may be strengthened by heat treatment. Because of the high silicon content, low melting point, good melt fluidity, and the final product will not be brittle, this series of alloys are mainly used to make aluminum alloy welding additives, such as brazing plates, welding rods and welding wires. In addition, due to the high wear resistance and high temperature resistance of some of this series of alloys, they are also used to make pistons and heat-resistant parts. The alloy containing about 5% of silicon is black-gray after anodizing and coloring, so it is used as building materials and manufacturing decorative parts.

4047 alloy aluminium coil is a non-heat treatable wrought alloy type with good corrosion resistance. It is a filler alloy, and is quite similar to aluminium / aluminum 4043 except for the higher silicon content in 4047 aluminum alloy. The higher silicon content provides improved fluidity during welding process with smooth finishes, as well as reduced shrinkage. It is suitable for elevated temperature operations.

Round Hole Perforated Metal
Hole Size
0.027" ~ 1.0"
Pitch(Hole centre to centre)
0.05" ~ 1.25"
Width
24" ~ 48"
Length
24" ~ 120"
Open Area
7% ~ 63%

Antiwear Patterned Aluminium Perforated Plate Sheet Metal 4047 Practical

Square Hole Perforated Metal
Hole Size
0.2" ~ 0.75"
Pitch(Hole centre to centre)
0.5" ~ 1" / Customized
Width
24" ~ 48"
Length
24" ~ 120"
Open Area
11% ~ 60%
Arrangement
Straight or staggered rows

Antiwear Patterned Aluminium Perforated Plate Sheet Metal 4047 Practical

Customized Hole Type Perforated Metal
Pattern
Fish scale hole, four-leaf clover, five-pointed star, irregular hole
Width
24" ~ 48"
Length
24" ~ 140"
Open Area
11% ~ 60%
Attached
According to drawings

Antiwear Patterned Aluminium Perforated Plate Sheet Metal 4047 Practical
